DA 2412

  • Can be made with Recycled Plastics Can be made with Recycled Plastics
Connect With Your ORBIS® Expert
Take the first step to a more sustainable supply chain and business. ORBIS is here to help.

ORBIS Dairy Cases are designed for the efficient distribution of fluid milk products and fruit juice from dairy processing facilities to grocery stores, convenience stores, and discount stores. Available in the two standard footprints mandated by the dairy industry, these cases offer exceptionally reinforced corners and bottoms. Designed for a long service life, ORBIS cases maintain their shape and performance through stacking, pressure washing, and transportation. These plastic containers are fully recyclable at the end of their service life. Asset tracking systems are available to reduce loss.

  • 19 x 13 footprint
  • Extended size holds more product
  • Fits 5-up on standard 40 x 48 pallets
  • Exceeds rigorous dairy standards
  • Universally compatible
  • Designed for automation
  • Optimal air flow maintains temperature
  • Reinforced base and corners for exceptional stacking strength
  • Bar code and RFID tag availability for efficient asset tracking
  • Available in FDA-approved materials (Please specify when requesting a quote.)


Outside Top Width In 13.1
Outside Bottom Length In 19.1
Outside Bottom Width In 13.1
Inside Top Length In 18.1
Inside Top Width In 12.2
Inside Bottom Length In 18.1
Inside Bottom Width In 12.1
Height In 11
Weight Lb 4
Prod Clearance In 10.7
53 Trailer Qty 2160


Container Hot Stamp

Hot Stamp identification is available for a wide variety of ORBIS totes. The original artwork must be supplied to ORBIS at the time of the order. Size, feasibility and available location of the hot stamp will vary for each container. Minimum shipment is required.

Molded-In Logo

Molded-In Logo identification is a type of permanent identification that is molded into product. Original artwork must be supplied to ORBIS at the time of the order. Availability, requirement, and location for the molded-in identification can vary for each product.

Compatible With

40 x 40 DY

Size (IN) : 40  x  40  x  5

Similar Products


Size (IN) : 13.1  x  13.1  x  12.1
